CJX2 LC1 50HZ AC Circuit Contactor Combined Into Electromagnetic Starter

Product Categories
YUEQING WINSTON ELECTRIC CO.,LTD.
Contact Now

CJX2 LC1 50HZ AC Circuit Contactor Combined Into Electromagnetic Starter

  • 1
  • 2
  • 3

Brand Name : Winston/OEM

Model Number : CJX2(LC1)

Certification : CE,ROSH

Place of Origin : China,Zhejiang

MOQ : 1PCS

Payment Terms : T/T,L/C,Paypal,Online Payment,RMB/USD

Supply Ability : 10000PCS/Month

Delivery Time : 3-15days after get payment.

Packaging Details : Export standard carton box

Current : 9A 12A 18A 25A 32A 40A 50A 65A 80A 95A

Phase : 3 phase

Use for : 3 phase motor

OEM : Yes

Contact Now

CJX2 LC1 50HZ AC Circuit Contactor Combined Into Electromagnetic Starter

CJX2 series AC Contactor is suitable for using in the circuits up to the rated voltage 660V AC50Hz or 60Hz, rated current up to 620A, for making, breaking, frequently starting & controllingthe AC motor. Combined with the auxiliary contact block, timer delay & machine-interlockingdevice etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter.With the thermal relay, it is combined into the electromagnetic starter. The product conforms toIEC60947-4-1 stardand.

TECHNICAL PARAMETER

Type CJX2-D09 CJX2-D12 CJX2-D18 CJX2-D25 CJX2-D32 CJX2-D40 CJX2-D50 CJX2-D65 CJX2-D80 CJX2-D95
Rated workingcurrent (A) AC3 9 12 18 25 32 40 50 65 80 95
AC4 3.5 5 7.7 8.5 12 18.5 24 28 37 44

Standardpower ratingsof 3-phasemotors

50/60Hz incategory AC-3

 220/230V 2.2 3 4 5.5 7.5 11 15 18.5 22 25
380/400V 4 5.5 7.5 11 15 18.5 22 30 37 45
415V 4 5.5 9 11 15 22 25 37 45 45
500V 5.5 7.5 10 15 18.5 22 30 37 55 55
660/690V 5.5 7.5 10 15 18.5 30 33 37 45 55
Rated heat current (A) 20 20 32 40 50 60 80 80 125 125
Electrical life AC3 (x104) 100 100 100 100 80 80 60 60 60 60
AC4 (x104) 20 20 20 20 20 15 15 15 10 10
Mechanical life (x104) 1000 1000 1000 1000 800 800 800 800 600 600
Number of the contacts 3P+NO 3P+NC+NO
3P+NC

Standard Control Circuit Voltage

Volts 24 42 48 110 220 230 240 380 400 415 440 500 600
50Hz B5 D5 E5 F5 M5 P5 U5 Q5 V5 N5 R5 S5 Y5
60Hz B6 D6 E6 F6 M6 - U6 Q6 - - R6 - -
50/60Hz B7 D7 E7 F7 M7 P7 U7 Q7 V7 N7 R7 - -

WIRING DIAGRAM

CJX2 LC1 50HZ AC Circuit Contactor Combined Into Electromagnetic Starter

FAQ

Q: How to order our product ?

A:1). Please tell us the model and quantity and other request you need.

2). We make the PI for you.

3). After you confirm the PI, we arrange the order for you after receiving your payment.

4). After the goods finished, we send the goods out to you and tell you the tracking number.

5). We will track your goods until you receive the goods.

Q: What's your warranty ?

A: Two years

Q: What's your shipment method?

A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.

Q: What's about MOQ?

A: First order MOQ=1pcs

Q: If i want to release order, what's the payment method you accept ?

A: We accept T/T, Paypal, Western union, L/C.

Q: If i want to release order, what's the process?

A: Thanks. You can send inquiry to us by Maoyt or send us by email, we will reply within 24hrs.
